Marantz 2230 2245 2270 4430 Phono Rebuild Set P700 Board Receiver Recap Kit
Up for sale here is this P700 phono board rebuild set for the Marantz 2230, 2245, 2270, or 4430. This is all the parts you need to rebuild a Marantz 2230, 2245, 2270, or 4430 P700 phono board. Over time the phono boards start developing issues with transistors, diodes, and capacitors, and often the old parts are weak and failing. We will make them new again! This kit includes 5 capacitors, two diodes, a pair of 1N4148s in series to replace the varistor at H709, and all 6 transistors. These are all high-quality brand new genuine parts. The capacitors are Nichicon PW, Nichicon KL, and Panasonic film caps, the diodes are new 1N4148 diodes, and the transistors are Onsemi KSC1815FTA (marked JCC1 815Y), which are the correct subs for the original transistors. These are extremely high-quality parts, and they are what I use when I rebuild Marantz gear. The 100 uf 50v capacitor at C713 is upgraded to a 220 uf 50v capacitor, which provides better filtering and is a better choice. The two 1 uf 250v Panasonic film caps are for C701/C702. If your board has the large brown caps for C701/702, you don't need to replace them, but if you have the little red caps there they should be replaced. If you have the large green caps there it's up to you. I will include surprisingly well-written instructions, but this is a little complicated, and you should know what you're doing and have a decent soldering iron. This kit should fix just about any phono board problems. Please see my pictures for details. US shipping and handling is $5, and international is $18, no matter what quantity you buy. All my small parts are set up for combined shipping, so just use the "add to cart" feature and then check out all at once, and it will combine shipping. If you have any questions, please ask. Looking for more parts? I have power switches, feet, pushbuttons, top case screws, bottom screws, faceplate screws, white LED fuse lamps, blue LED fuse lamps, 6.3v bi-pin bulbs, 8v bi-pin bulbs, 12v bi-pin bulbs, wired 8v 60ma bulbs, new power cords, new main capacitors for the Marantz 1060/2230, wired Pioneer speaker plug replacements, new 630v yellow film capacitors at 30 different values, a large variety of transistors for vintage stereo repair, new 250v yellow film crossover capacitors, and more. Just use "add to cart" on everything you want and then check out for combined shipping.
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Model | 2230 |
| Country/Region Of Manufacture | United States |
| Brand | Marantz |
